NTPsec

ntp1.wiktel.com

Report generated: Mon May 27 16:45:04 2024 UTC
Start Time: Mon May 20 16:45:02 2024 UTC
End Time: Mon May 27 16:45:02 2024 UTC
Report Period: 7.0 days

Top   Daily Stats   Weekly Stats

Local Clock Time/Frequency Offsets

local offset plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Time Offset -12.682 -3.604 -2.893 -0.627 4.133 5.009 6.742 7.026 8.613 2.263 0.002 µs -3.45 7.099
Local Clock Frequency Offset 17.544 17.572 17.589 17.652 17.727 17.744 17.773 0.138 0.172 0.041 17.653 ppm 7.919e+07 3.401e+10

The time and frequency offsets between the ntpd calculated time and the local system clock. Showing frequency offset (red, in parts per million, scale on right) and the time offset (blue, in μs, scale on left). Quick changes in time offset will lead to larger frequency offsets.

These are fields 3 (time) and 4 (frequency) from the loopstats log file.



Local RMS Time Jitter

local jitter plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Time Jitter 0.214 0.340 0.413 0.610 0.927 1.617 5.470 0.514 1.277 0.220 0.643 µs 17 104.7

The RMS Jitter of the local clock offset. In other words, how fast the local clock offset is changing.

Lower is better. An ideal system would be a horizontal line at 0μs.

RMS jitter is field 5 in the loopstats log file.



Local RMS Frequency Jitter

local stability plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Frequency Jitter 0.182 0.289 0.398 0.935 1.907 2.244 2.849 1.509 1.955 0.456 1.007 ppb 6.144 17.73

The RMS Frequency Jitter (aka wander) of the local clock's frequency. In other words, how fast the local clock changes frequency.

Lower is better. An ideal clock would be a horizontal line at 0ppm.

RMS Frequency Jitter is field 6 in the loopstats log file.



Local Clock Time Offset Histogram

local offset histogram plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Offset -12.682 -3.604 -2.893 -0.627 4.133 5.009 6.742 7.026 8.613 2.263 0.002 µs -3.45 7.099

The clock offsets of the local clock as a histogram.

The Local Clock Offset is field 3 from the loopstats log file.



Server Offsets

peer offsets plot

The offset of all refclocks and servers. This can be useful to see if offset changes are happening in a single clock or all clocks together.

Clock Offset is field 5 in the peerstats log file.



Server Offset 128.138.141.177

peer offset 128.138.141.177 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 128.138.141.177 -701.446 -356.384 -226.939 -94.641 202.879 389.591 778.395 429.818 745.975 138.410 -64.264 µs -6.588 18.28

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2001:470:0:2c8::2 (clock.nyc.he.net)

peer offset 2001:470:0:2c8::2 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2001:470:0:2c8::2 (clock.nyc.he.net) -59.752 -47.726 -19.274 -0.381 3.332 27.990 120.290 22.605 75.716 11.676 -1.586 ms -3.05 37.01

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 209.87.233.54

peer offset 209.87.233.54 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 209.87.233.54 -8.954 -3.035 -1.358 1.180 3.199 4.442 9.444 4.557 7.477 1.432 1.111 ms -1.072 6.395

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2602:fd53:11e:123::2 (time2.mbix.ca)

peer offset 2602:fd53:11e:123::2 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2602:fd53:11e:123::2 (time2.mbix.ca) -2.381 -1.629 -0.642 -0.076 0.671 1.643 3.858 1.313 3.272 0.516 -0.042 ms -2.532 20.29

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2606:4700:f1::123 (time.cloudflare.com)

peer offset 2606:4700:f1::123 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2606:4700:f1::123 (time.cloudflare.com) -1.404 -1.337 -0.777 -0.616 -0.192 -0.112 -0.080 0.584 1.225 0.188 -0.594 ms -84.38 412.3

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2607:f128:1:3::dd1 (dns1.steadfast.net)

peer offset 2607:f128:1:3::dd1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2607:f128:1:3::dd1 (dns1.steadfast.net) 511.013 534.471 546.744 584.601 621.363 634.387 663.320 74.619 99.916 22.243 584.272 µs 1.621e+04 4.115e+05

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2607:f388::123:1 (ntp1.doit.wisc.edu)

peer offset 2607:f388::123:1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2607:f388::123:1 (ntp1.doit.wisc.edu) -13.018 -13.001 -12.985 -12.943 -12.900 -12.885 -12.863 0.085 0.116 0.025 -12.942 ms -1.345e+08 6.893e+10

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset PPS(0)

peer offset PPS(0) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset PPS(0) -12.683 -3.605 -2.894 -0.628 4.134 5.010 6.743 7.028 8.615 2.264 0.001 µs -3.45 7.1

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Jitters

peer jitters plot

The RMS Jitter of all refclocks and servers. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 128.138.141.177

peer jitter 128.138.141.177 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 128.138.141.177 129.801 263.306 371.734 612.034 847.036 986.313 1,785.437 475.302 723.007 149.927 611.584 µs 38.78 156.1

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2001:470:0:2c8::2 (clock.nyc.he.net)

peer jitter 2001:470:0:2c8::2 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2001:470:0:2c8::2 (clock.nyc.he.net) 0.006 0.010 0.014 0.043 1.314 7.705 71.881 1.301 7.696 2.928 0.461 ms 13.9 296.1

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 209.87.233.54

peer jitter 209.87.233.54 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 209.87.233.54 1.104 2.130 3.403 9.324 20.652 34.131 160.025 17.250 32.001 8.955 10.634 ms 9.275 131.6

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2602:fd53:11e:123::2 (time2.mbix.ca)

peer jitter 2602:fd53:11e:123::2 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2602:fd53:11e:123::2 (time2.mbix.ca) 5.715 10.221 14.104 31.421 82.361 220.236 875.991 68.257 210.015 48.011 40.983 µs 8.399 111.1

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2606:4700:f1::123 (time.cloudflare.com)

peer jitter 2606:4700:f1::123 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2606:4700:f1::123 (time.cloudflare.com) 5.937 8.840 11.461 26.341 87.181 299.684 2,082.163 75.720 290.844 104.224 42.213 µs 12.46 219.8

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2607:f128:1:3::dd1 (dns1.steadfast.net)

peer jitter 2607:f128:1:3::dd1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2607:f128:1:3::dd1 (dns1.steadfast.net) 10.482 13.189 17.202 32.485 66.752 200.392 1,365.893 49.550 187.203 46.883 39.119 µs 14.81 344.3

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2607:f388::123:1 (ntp1.doit.wisc.edu)

peer jitter 2607:f388::123:1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2607:f388::123:1 (ntp1.doit.wisc.edu) 0.016 0.025 0.037 0.096 4.830 6.507 64.769 4.793 6.481 2.337 0.695 ms 11.31 281.2

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter PPS(0)

peer jitter PPS(0) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter PPS(0) 0.074 0.223 0.326 0.675 1.464 2.015 10.950 1.138 1.792 0.399 0.765 µs 6.378 42.56

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Summary


Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset 17.544 17.572 17.589 17.652 17.727 17.744 17.773 0.138 0.172 0.041 17.653 ppm 7.919e+07 3.401e+10
Local Clock Time Offset -12.682 -3.604 -2.893 -0.627 4.133 5.009 6.742 7.026 8.613 2.263 0.002 µs -3.45 7.099
Local RMS Frequency Jitter 0.182 0.289 0.398 0.935 1.907 2.244 2.849 1.509 1.955 0.456 1.007 ppb 6.144 17.73
Local RMS Time Jitter 0.214 0.340 0.413 0.610 0.927 1.617 5.470 0.514 1.277 0.220 0.643 µs 17 104.7
Server Jitter 128.138.141.177 129.801 263.306 371.734 612.034 847.036 986.313 1,785.437 475.302 723.007 149.927 611.584 µs 38.78 156.1
Server Jitter 2001:470:0:2c8::2 (clock.nyc.he.net) 0.006 0.010 0.014 0.043 1.314 7.705 71.881 1.301 7.696 2.928 0.461 ms 13.9 296.1
Server Jitter 209.87.233.54 1.104 2.130 3.403 9.324 20.652 34.131 160.025 17.250 32.001 8.955 10.634 ms 9.275 131.6
Server Jitter 2602:fd53:11e:123::2 (time2.mbix.ca) 5.715 10.221 14.104 31.421 82.361 220.236 875.991 68.257 210.015 48.011 40.983 µs 8.399 111.1
Server Jitter 2606:4700:f1::123 (time.cloudflare.com) 5.937 8.840 11.461 26.341 87.181 299.684 2,082.163 75.720 290.844 104.224 42.213 µs 12.46 219.8
Server Jitter 2607:f128:1:3::dd1 (dns1.steadfast.net) 10.482 13.189 17.202 32.485 66.752 200.392 1,365.893 49.550 187.203 46.883 39.119 µs 14.81 344.3
Server Jitter 2607:f388::123:1 (ntp1.doit.wisc.edu) 0.016 0.025 0.037 0.096 4.830 6.507 64.769 4.793 6.481 2.337 0.695 ms 11.31 281.2
Server Jitter PPS(0) 0.074 0.223 0.326 0.675 1.464 2.015 10.950 1.138 1.792 0.399 0.765 µs 6.378 42.56
Server Offset 128.138.141.177 -701.446 -356.384 -226.939 -94.641 202.879 389.591 778.395 429.818 745.975 138.410 -64.264 µs -6.588 18.28
Server Offset 2001:470:0:2c8::2 (clock.nyc.he.net) -59.752 -47.726 -19.274 -0.381 3.332 27.990 120.290 22.605 75.716 11.676 -1.586 ms -3.05 37.01
Server Offset 209.87.233.54 -8.954 -3.035 -1.358 1.180 3.199 4.442 9.444 4.557 7.477 1.432 1.111 ms -1.072 6.395
Server Offset 2602:fd53:11e:123::2 (time2.mbix.ca) -2.381 -1.629 -0.642 -0.076 0.671 1.643 3.858 1.313 3.272 0.516 -0.042 ms -2.532 20.29
Server Offset 2606:4700:f1::123 (time.cloudflare.com) -1.404 -1.337 -0.777 -0.616 -0.192 -0.112 -0.080 0.584 1.225 0.188 -0.594 ms -84.38 412.3
Server Offset 2607:f128:1:3::dd1 (dns1.steadfast.net) 511.013 534.471 546.744 584.601 621.363 634.387 663.320 74.619 99.916 22.243 584.272 µs 1.621e+04 4.115e+05
Server Offset 2607:f388::123:1 (ntp1.doit.wisc.edu) -13.018 -13.001 -12.985 -12.943 -12.900 -12.885 -12.863 0.085 0.116 0.025 -12.942 ms -1.345e+08 6.893e+10
Server Offset PPS(0) -12.683 -3.605 -2.894 -0.628 4.134 5.010 6.743 7.028 8.615 2.264 0.001 µs -3.45 7.1
Summary as CSV file


Glossary:

frequency offset:
The difference between the ntpd calculated frequency and the local system clock frequency (usually in parts per million, ppm)
jitter, dispersion:
The short term change in a value. NTP measures Local Time Jitter, Refclock Jitter, and Server Jitter in seconds. Local Frequency Jitter is in ppm or ppb.
kurtosis, Kurt:
The kurtosis of a random variable X is the fourth standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of kurtosis. A normal distribution has a kurtosis of three. NIST describes a kurtosis over three as "heavy tailed" and one under three as "light tailed".
ms, millisecond:
One thousandth of a second = 0.001 seconds, 1e-3 seconds
mu, mean:
The arithmetic mean: the sum of all the values divided by the number of values. The formula for mu is: "mu = (∑xi) / N". Where xi denotes the data points and N is the number of data points.
ns, nanosecond:
One billionth of a second, also one thousandth of a microsecond, 0.000000001 seconds and 1e-9 seconds.
percentile:
The value below which a given percentage of values fall.
ppb, parts per billion:
Ratio between two values. These following are all the same: 1 ppb, one in one billion, 1/1,000,000,000, 0.000,000,001, 1e-9 and 0.000,000,1%
ppm, parts per million:
Ratio between two values. These following are all the same: 1 ppm, one in one million, 1/1,000,000, 0.000,001, and 0.000,1%
‰, parts per thousand:
Ratio between two values. These following are all the same: 1 ‰. one in one thousand, 1/1,000, 0.001, and 0.1%
refclock:
Reference clock, a local GPS module or other local source of time.
remote clock:
Any clock reached over the network, LAN or WAN. Also called a peer or server.
time offset:
The difference between the ntpd calculated time and the local system clock's time. Also called phase offset.
σ, sigma:
Sigma denotes the standard deviation (SD) and is centered on the arithmetic mean of the data set. The SD is simply the square root of the variance of the data set. Two sigma is simply twice the standard deviation. Three sigma is three times sigma. Smaller is better.
The formula for sigma is: "σ = √[ ∑(xi-mu)^2 / N ]". Where xi denotes the data points and N is the number of data points.
skewness, Skew:
The skewness of a random variable X is the third standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of skewness. Wikipedia describes it best: "The qualitative interpretation of the skew is complicated and unintuitive."
A normal distribution has a skewness of zero.
upstream clock:
Any server or reference clock used as a source of time.
µs, us, microsecond:
One millionth of a second, also one thousandth of a millisecond, 0.000,001 seconds, and 1e-6 seconds.



This page autogenerated by ntpviz, part of the NTPsec project
html 5    Valid CSS!
